SKU: BSC

Cast Iron Flanged Basket Strainer

From $192.50

Inc GST
In Stock
Make an Enquiry
  • Ductile Iron Flanged Table E Basket Strainer Strainer
  • 0 to 16 Bar Pressure Range
  • 0°C to 80°C Temperature Range
  • Tested to API598
Model DN (mm) Pressure Range Media Temp Weight (kg) Plug Size Mesh Size (⌀mm)
BSC-050 50 0 to 16 BAR 0 to 80°C 11 ½” 2
BSC-065 65 0 to 16 BAR 0 to 80°C 19 ¾” 2
BSC-080 80 0 to 16 BAR 0 to 80°C 21 ¾” 2
BSC-100 100 0 to 16 BAR 0 to 80°C 33 1” 2
BSC-125 125 0 to 16 BAR 0 to 80°C 43 1” 3
BSC-150 150 0 to 16 BAR 0 to 80°C 60 1” 3
BSC-200 200 0 to 16 BAR 0 to 80°C 100 1 ½” 5
BSC-250 250 0 to 16 BAR 0 to 80°C 151 1 ½” 5
BSC-300 300 0 to 16 BAR 0 to 80°C 270 2” 5
BSC-350 350 0 to 16 BAR 0 to 80°C 450 2” 5
BSC-400 400 0 to 16 BAR 0 to 80°C 500 2” 5
BSC-450 450 0 to 16 BAR 0 to 80°C 643 2” 5
BSC-500 500 0 to 16 BAR 0 to 80°C 850 2” 5
BSC-600 600 0 to 16 BAR 0 to 80°C 1250 2” 5

Cast Iron Basket Strainer Dimensions

DN L D K G B f f-⌀d H1 H2
50 207 165 114 90 19 3 4-18 114 98
65 210 185 127 103 19 3 4-18 129 112
80 251 200 146 122 19 3 4-18 142 125
100 292 220 178 154 19 3 8-18 165 160
125 334 250 210 186 19 3 8-18 173 185
150 378 285 235 207 19 3 8-22 165 235
200 475 340 292 264 20 3 12-22 215 295
250 511 405 356 328 22 3 12-26 250 340
300 667 460 406 374 24.5 3 12-26 283 423
350 769 520 470 438 26.5 3 12-26 345 540
400 842 580 521 489 28 4 12-26 390 590
450 890 640 584 552 30 4 16-26 402 618
500 900 715 641 609 31.5 4 16-26 441 696
600 1000 840 756 717 36 5 16-33 523 834

All dimensions in mm unless shown otherwise.

Cast Iron Basket Strainer Construction

Number Part Material
1 Body Cast Iron
2 Screen 304 SS
3 Cover Gasket NBR
4 Cover Cast Iron
5 Bolt 201 SS
6 Bolt Nut 201 SS
7 Plug 304 SS

Size 50mm to 600mm
Body FBE Coated Cast Iron
Mesh 304 Stainless Steel
Pressure Range 0 to 16 BAR
Flanged AS2129 Table E / AS4087 PN16
Factory Accredited CE, ISO 9001, TUV, WRAS
